- 規格型號：40374041
- 頻率：32.768K
- 尺寸：3215mm
- 產品描述：NX3215SA-32.768K-STD-MUA-14,3215小型貼片晶振,NDK電子晶振,32.768KHz關鍵頻率輸出,專為計時,時鐘同步等核心功能設計,頻率穩定性高,相位噪聲低,能有效提升設備的計時精度.適配綠色電子產業發展需求.
NX3215SA-32.768K-STD-MUA-14,3215小型貼片晶振,NDK電子晶振
.png)
.png)
NX3215SA-32.768K-STD-MUA-14,3215小型貼片晶振,NDK電子晶振
NX3215SA-32.768K-STD-MUA-14晶振,作為3215小型貼片晶振的標桿產品,聚焦高頻穩定性與小型化需求,32.768KHz音叉晶振頻率輸出精準,頻率老化率低,長期使用仍能維持優異的計時精度.產品采用精密的晶體切割與封裝工藝,具備極強的環境適應性,可在高低溫,濕度變化等復雜環境下穩定工作.適配消費電子,工業控制,汽車電子等多個領域,尤其適用于對計時精度和環境適應性要求嚴苛的車載傳感器,工業計時器,智能終端等設備,為各類電子系統提供穩定,精準的時鐘信號支持.
.png)
NX3215SA-32.768K-STD-MUA-14,3215小型貼片晶振,NDK電子晶振
| 原廠型號 Originalmodel： | NX3215SA-32.768K-STD-MUA-14 | 品牌brand： | 日產進口NDK晶振 |
| 品牌brand： | NDK | 高度PackageHeight： | 0.8mm |
| 型號名稱 Modelname： | NX3215SA | 溫度OperatingTemperature | -40+85℃ |
| Type系列： | MHz Crystal | 腳位Termination： | 2-Pad |
| 頻率 frequency： | 32.768K | 封裝類型PackageType： | 2-Smd |
| frequencytolerance頻率容差 | 20PP | 最小包裝數MPQ： | 3000 |
| Loadcapacitance 負載電容 | 6PF | Packaging 包裝 | TapeandReel |
| Size/Dimension尺寸 | 3215mm | 安裝方式 Installation： | Surfacemount |
.png)
NX3215SA-32.768K-STD-MUA-14,3215小型貼片晶振,NDK電子晶振
NX3215SA-32.768K-STD-MUA-14,3215小型貼片晶振,NDK電子晶振
| NZ1612SH | 12MHZ | NSC5152A | NZ1612SH-12.000MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 12.288MHZ | NSC5152A | NZ1612SH-12.288MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 13MHZ | NSC5152A | NZ1612SH-13.000MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 16MHZ | NSC5152A | NZ1612SH-16.000MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 19.2MHZ | NSC5152A | NZ1612SH-19.200MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 20MHZ | NSC5152A | NZ1612SH-20MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 24MHZ | NSC5152A | NZ1612SH-24MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 25MHZ | NSC5152A | NZ1612SH-25MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 26MHZ | NSC5152A | NZ1612SH-26MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 40MHZ | NSC5152A | NZ1612SH-40MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 48MHZ | NSC5152A | NZ1612SH-48MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 50MHZ | NSC5152A | NZ1612SH-50MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 52MHZ | NSC5152A | NZ1612SH-52MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 80MHZ | NSC5152A | NZ1612SH-80MHZ-NSC5152A | 1.6x1.2 |
| NZ1612SH | 12MHZ | NSC5152B | NZ1612SH-12MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 12.288MHZ | NSC5152B | NZ1612SH-12.288MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 13MHZ | NSC5152B | NZ1612SH-13MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 16MHZ | NSC5152B | NZ1612SH-16MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 19.2MHZ | NSC5152B | NZ1612SH-19.2MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 20MHZ | NSC5152B | NZ1612SH-20MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 24MHZ | NSC5152B | NZ1612SH-24MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 25MHZ | NSC5152B | NZ1612SH-25MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 26MHZ | NSC5152B | NZ1612SH-26MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 40MHZ | NSC5152B | NZ1612SH-40MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 48MHZ | NSC5152B | NZ1612SH-48MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 50MHZ | NSC5152B | NZ1612SH-50MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 52MHZ | NSC5152B | NZ1612SH-52MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 80MHZ | NSC5152B | NZ1612SH-80MHZ-NSC5152B | 1.6x1.2 |
| NZ1612SH | 12MHZ | NSC5152C | NZ1612SH-12MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 12.288MHZ | NSC5152C | NZ1612SH-12.288MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 13MHZ | NSC5152C | NZ1612SH-13MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 16MHZ | NSC5152C | NZ1612SH-16MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 19.2MHZ | NSC5152C | NZ1612SH-19.2MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 20MHZ | NSC5152C | NZ1612SH-20MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 24MHZ | NSC5152C | NZ1612SH-24MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 25MHZ | NSC5152C | NZ1612SH-25MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 26MHZ | NSC5152C | NZ1612SH-26MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 40MHZ | NSC5152C | NZ1612SH-40MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 48MHZ | NSC5152C | NZ1612SH-48MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 50MHZ | NSC5152C | NZ1612SH-50MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 52MHZ | NSC5152C | NZ1612SH-52MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 80MHZ | NSC5152C | NZ1612SH-80MHZ-NSC5152C | 1.6x1.2 |
| NZ1612SH | 12MHZ | NSC5152D | NZ1612SH-12MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 12.288MHZ | NSC5152D | NZ1612SH-12.288MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 13MHZ | NSC5152D | NZ1612SH-13MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 16MHZ | NSC5152D | NZ1612SH-16MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 19.2MHZ | NSC5152D | NZ1612SH-19.2MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 20MHZ | NSC5152D | NZ1612SH-20MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 24MHZ | NSC5152D | NZ1612SH-24MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 25MHZ | NSC5152D | NZ1612SH-25MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 26MHZ | NSC5152D | NZ1612SH-26MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 40MHZ | NSC5152D | NZ1612SH-40MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 48MHZ | NSC5152D | NZ1612SH-48MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 50MHZ | NSC5152D | NZ1612SH-50MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 52MHZ | NSC5152D | NZ1612SH-52MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 80MHZ | NSC5152D | NZ1612SH-80MHZ-NSC5152D | 1.6x1.2 |
| NZ1612SH | 12MHZ | NSC5103A | NZ1612SH-12MHZ-NSC5103A | 1.6x1.2 |
| NZ1612SH | 12.288MHZ | NSC5103A | NZ1612SH-12.288MHZ-NSC5103A | 1.6x1.2 |
| NZ1612SH | 13MHZ | NSC5103A | NZ1612SH-13MHZ-NSC5103A | 1.6x1.2 |
| NZ1612SH | 16MHZ | NSC5103A | NZ1612SH-16MHZ-NSC5103A | 1.6x1.2 |
